Forestry trailer RW14
The RW 14 is a very stable vehicle with double frame 200 x 100 x 6 mm hollow sections. The drawbar steering with 2 large sized cylinders ensures a great maneuverability and good handling charasteristic.
Frame-double tube (mm) | 200x100x6 |
Loading capacity (kg) | 11.860 |
Loading space (m2) | 2,4 |
Length of the loading area (mm) | 3.725 |
The lowest point from the ground (mm) | 420 |
Turning angle | +/-22° |
Width (mm) | 2.310 |
Length (mm) | 5.800 |
Own weight (kg) | cca 2.140 |
Height of the arms (mm) | 1.200 |
Frame tube steering | Hydraulic cylinder- 2xcil. |
Wheels | 400/60-15.5/14PR |
Bolsters | 4 pairs |
Brakes | 2x hydraulic |
Operating pressure (bar) | 180 |
Brakes | Various combination- hydraulic, overrun, airbrakes |
Extension | 1,2m or 1,6 m with 2 extra bolsters |
Standing platform | Yes |
Drawbar | Standard or lower (By lower drawbar, overrun brakes are not an option) |
Mudguard | Yes |
Troughs for biomass | Standard or half troughs |
Tyres | Different tire sizes with different profiles |
